Full Bore Retrievable Mechanical Well Packers High Pressure RTTS For DST Service

  • 1
  • 2

Brand Name : ZZ TOP OIL TOOLS

Model Number : APR Tools

Certification : ISO, API

Place of Origin : China

MOQ : 1 set

Price : USD 1-10000/set

Payment Terms : L/C, T/T, D/P

Supply Ability : 10 set/month

Delivery Time : 30-50 days

Packaging Details : Pollywood

Product : Full Bore Retrievable Packer

Material : Alloy Steel / Inconnel

Size : 4 1/2 inch to 20 inch

Working Pressure : 10000psi

Application : Oil & Gas Well Dowhole Drill Stem Testing Service

Connection : IF, EUE , CAS

Working Condition : Oil & Gas & H2S service

Working Temperature : Up to 425oF

Contact Now

Full Bore Retrievable Packer High Pressure RTTS Packer For DST Service

The Full Bore Retrievable Packer is a part of Drill Stem Testing Tool String, this retrievable packer is also called RTTS Packer in Halliburton type. The retrievable packer is designed with a full opening, which is hookwall type packer for use in testing, treating, and squeeze cementing operations. The full opening permits pumping large volumes of fluid with a minimum pressure drop, and allows the passage of a through tubing type perforating gun. This helps make the tool usable for multiple operations with one trip in the hole-such as perforate, test, treat, squeeze, perforate, etc. Generally, the tool is composed of a packer body assembly and circulating valve assembly. It may also includes a safety joint.

Specifcation of Full Bore Retrievable Packer / RTTS Packer

Size(in) Casing Range(lb/ft) Size(in) Casing Range(lb/ft)

4 1/2

 9.5 8 5/8 24-49
15.1-18.1

9 5/8

 40-71.8
11.6-13.5 29.3-53.5

5

 23

10 3/4

 32.75-55.5
15-18 60.7-81
11.5-13

11 3/4

 38-54

5 1/2

 23-26 60-71
20-23

13 3/8

 48-72
13-20 72-98
6 15-23

16

 75-109
6 5/8 24-32 109-146

7

 17-38 18 5/8 78-118
49.5

20

 94-133
7 5/8 20-39 169-204
