Expendable Seat Catcher Sub For High Pressure Well Completion Operations

Name: Expendable Seat Catcher Sub For High Pressure Well Completion Operations
Brand: ZZ TOP OIL TOOLS
Price: 1 USD

Expendable Seat Catcher Sub For High Pressure Well Completion Operations Manufactures

Brand Name : ZZ TOP OIL TOOLS

Model Number : Expendable Seat Catcher Sub

Certification : ISO, API

Place of Origin : China

MOQ : 1 set

Price : USD 1-10000/set

Payment Terms : L/C, T/T, D/P

Supply Ability : 10 set/month

Delivery Time : 30-50 days

Packaging Details : Pollywood

Product : Expendable Seat Catcher Sub

Application : Oil & Gas Well Completion Operation

Usage : Setting the hydraulic set packer.

Tubing Size : 2 3/8" - 5"

Working Pressure : 10000 psi

Connection : IF, EUE , CAS

Working Condition : Oil & Gas & H2S service

Working Temperature : Up to 425oF

Contact Now

Expendable Seat Catcher Sub For High Pressure Well Completion Operations

The Expendable Seat Sub is installed in the tubing string below the packer, which is used to set the hydraulic setting packer, a ball in the catcher sub is circulated down through the tubing and reaches the ball seat of the ball seat sub, and then pressure is applied to set the packer. Once the packer is set, the pressure is increased to shear out the ball seat of the ball seat sub, it has a full-open ID when the ball is expended

Features and Benefits:

The shear screw cannot accidentally fall off and affect the shear value;
Compatible with standard tubing or packer;
Simple structure, convenient installation and proper cost;
High strength, applicable pressure rating of 10,000psi;
The opening pressure is stable;

Technical parameter of Expendable Seat Catcher Sub

Specification
Tubing size		MAX.OD		Min.ID(after being sheared)
in	mm	in	mm	in	mm
2 3/8	60.33	3.063	77.80	1.750	44.45
				1.875	47.63
2 7/8	73.03	3.668	93.17	2.250	57.15
3 1/2	88.90	4.500	114.30	2.750	69.85
				2.875	73.03
5.000	127.00	5.669	144.00	4.134	105.00
