Motorhead Assembly / MHA Coiled Tubing Tools with 10000Psi W.P.

Name: Motorhead Assembly MHA Coiled Tubing Tools with 10000Psi WP
Brand: ZZ TOP OIL TOOLS
Price: 1 USD

Motorhead Assembly / MHA Coiled Tubing Tools with 10000Psi W.P. Manufactures

Brand Name : ZZ TOP OIL TOOLS

Model Number : Motorhead Assembly

Certification : ISO, API

Place of Origin : China

MOQ : 1 set

Price : USD 1-10000/set

Payment Terms : L/C, T/T, D/P

Supply Ability : 10 set/month

Delivery Time : 30-50 days

Packaging Details : Pollywood

Product : Motorhead Assembly

Application : Oil well Coiled tubing operation

Usage : Coiled Tubing Tool String

Material : Alloy Steel

Size : 1 3/4" - 3 1/8"

Connection : AMMT, PAC

Working Condition : Oil & Gas & H2S service

Delivery : 20-30 days

Contact Now

Motorhead Assembly / MHA Coiled Tubing Tools with 10000Psi W.P.

The Motorhead Assembly is the one of components of coiled tubing tools. The MHA has been designed with compact, heavy duty, integrated BHA components. The Motorhead Assembly consists of Double Flapper Check Valve, Heavy Duty Hydraulic Disconnect and the Dual Activated Circulation Valve. This kind of compact design of motorhead assembly gives an overall length saving of approximately 30% over the use of conventional individual components.The tubing connector has been deliberately eliminated to give the added flexibility of operator choice for the connector type and coil tubing size.

High torque capabilities are achieved through positive torque drive teeth between the top sub and the main body of the tool. The heavy duty hydraulic disconnect is therefore ideally suited for high torque, heavy duty coiled tubing drilling operations where maximum performance and durability are essential.

Specification of Heavy Duty Motorhead Assembly

Specification of Motorhead Assembly
Max OD (in)	Min ID (in)	Thread
1.687	0.406	1"AMMT
1.750	0.406	1"AMMT
2.125	0.406	1.5"AMMT
2.375	0.625	1.5"AMMT
2.875	0.750	2 3/8"PAC
3.125	0.812	2 3/8"PAC

Motorhead Assembly / MHA Coiled Tubing Tools with 10000Psi W.P.

Product Tags:

MHA Coiled Tubing Tools

Motorhead Assembly Coiled Tubing Tools

Motorhead Assembly / MHA Coiled Tubing Tools with 10000Psi W.P. Images
